Introduction:Advantages 1: Advanced technologyDue to its advanced technology, reliable operation, low and stable dew point and other advantages, the "DEMAGO" brand cold dryer conforms to the "general
- Product features
- Product specification
- Accessories
-
Introduction:Advantages 1: Advanced technologyDue to its advanced technology, reliable operation, low and stable dew point and other advantages, the "DEMAGO" brand cold dryer conforms to the "general compressed air refrigerated dryer" and the "general compressed air refrigerated dryer controller".Advantage 2: the heat exchange is in the countercurrent modeThe heat transfer coefficient is high due to the selection of, threaded tube or smooth tube, and the heat exchange mode of countercurrent heat recovery is more energy-saving and stable than the ordinary countercurrent mode.Advantages 3: gas-liquid separationAs the gas-liquid separator developed independently is adopted, the separation efficiency is higher than other types of separators, and the separation rate is more than 99%.Advantages 4: Effluent drainage and smooth drainageDue to the use of independent technology, the condensed water of the refrigerated dryer is fully separated and discharged out of the dryer through a drain valve with reliable performance, which greatly reduces the failure of the dryer during operation and improves the quality of the air source, so that the DEMAGO brand dryer can operate stably and orderly under different working conditions.Advantage 5: Classification of professional working conditionsIn order to make the refrigerated dryers operate stably and energy-efficient under different working conditions, Demag refrigerated dryers are divided into high-temperature air cooling, high-temperature water cooling, normal temperature air cooling and normal temperature water cooling according to customer needs and actual working conditions.Operating conditions and technical indicatorsInlet temperature: ≤ 80 ℃Cooling method: Air coolingInlet pressure: 0.6~1.0MpaPressure drop ≤ 0.03MpaDew point: 2~10 ℃Refrigerant: R22 (environmental refrigerant optional)Ambient temperature ≤ 38 ℃
-
model
Air handling capacity（Nm³/min）
Power Supply
（V/HZ）
Compressor power（HP）
Air inlet and outlet diameter
weight（KG）
Overall dimensions
L
W
H
DM010GF
1
220/50
0.65
Rp1
50
720
375
670
DM015GF
1.5
085
60
750
400
700
DM026GF
2.6
1
80
800
450
730
DM040GF
4.0
1.25
Rp1½
105
800
475
800
DM065GF
6.5
1.75
136
950
500
880
DM085GF
8.5
2
Rp2
165
1060
560
983
DM110GF
11
380/50
3
195
1180
630
1092
DM138GF
13.8
3.5
255
1180
670
1092
DM150GF
17
380/50
4
DN65
300
1240
670
1188
DM200GF
23
5
DN80
385
1420
790
1340
DM250GF
27
6
400
1650
820
1370
DM300GF
35
8
550
1650
820
1370
DM400GF
45
10
DN100
630
1850
920
1550
DM500GF
55
12
DN125
680
1980
930
1826
DM600GF
65
15
720
2080
930
1834
